Delivering next-generation store performance for wide or multiple exits in a sleek, transparent design – The Sensormatic Synergy 2.5 Acrylic Pedestal.

The Sensormatic Synergy 2.5 Acrylic Pedestal is a key element of the Sensormatic Synergy suite. Its thin, narrow, open-frame design is constructed of high-quality acrylic, preserving store aesthetics and delivering the right look for virtually any retail setting. Ideal for wide or multiple exits, this detection system uses Sensormatic AM EAS technology to provide the highest level of theft detection with up to 2.5m (8ft 2in) of coverage between pedestals to maximize customer flow. The integrated audio and visual alarms notify staff personnel if protected merchandise passes through the detection zone. The multiple audio and visual alarms can be customized for different event types, mapping the audio and ambient lighting options to reflect the source of the alert, such as foil-lined bags and jammer devices. The pedestal features embedded, multiple-beam people-counting sensors designed for optimal accuracy. With the Synergy network card, these sensors provide visibility into shopper visits to enhance store performance and increase conversion rates.

Integrating directional traffic information with EAS alarm events allows the sensors to discern between inbound and outbound traffic, virtually eliminating unintended alarms triggered by shoppers carrying protected merchandise near the pedestals. Peoplecounting sensors also enable a “poweron-demand” feature that puts the system into low-power standby mode during periods of low or no traffic activity to reduce power consumption up to 90%. To effectively combat Organized Retail Crime, the AMS9060 Controller — part of this flexible and modular system — can be enhanced with the optional integrated Metal-Foil Detection plug-in card. The network plug-in card, standard with this pedestal system, delivers remote management, EAS and Traffic Intelligence.

Through system configuration, “tags-tooclose” is an offered feature developed to help retailers maximize valuable selling floor space near the pedestals. This feature helps reduce unnecessary and costly service calls and decreases nuisance alarms to enhance the shopper experience. Another standard systemconfigured feature is Jammer Detection which triggers a pedestal alarm as soon as an electronic signal from a jammer device is detected, helping eliminate the threat of would-be thieves attempting to defeat the system.

Retailer Values

  • SuperTag, the gold standard in assetprotection, features a patented clampdesign for superior defeat resistance
  • Transparent acrylic form factor preserves store aesthetics
  • Consistent 2.5m (8ft 2in) global detection performance protects critical assets
  • Embedded people-counting sensors capture shopper visits to help maximize store performance
  • Optional Metal-Foil Detection alerts staff when foil-lined bags or clothing enter the store environment, helping combat shrink and ORC
  • Standard network plug-in card delivers store-front alarm event and Traffic Intelligence to enhance loss prevention efforts and increase shopper visibility
  • “Tags-too-close” feature helps reduce unnecessary and costly service calls and maximizes valuable selling floor space near the pedestals
  • Jammer detection helps reduce shrink by notifying staff of attempts to disable the EAS system using a separate audible alarm
  • Customizable alarm tones and LED alarm light identify unique events to help reduce shrink
  • Remote alarm option alerts staff of alarm events anywhere in store
  • Service connection port allows remote diagnostics to help reduce in-store service time

Required Choices

Base Covers

ZSSB-E1180-SS
Stainless Steel (Qty. 1=1 pair)
ZSSB-E1180-SB
Stainless Steel Black (Qty. 1=1 pair)

ZSSB-E1190CG
Cool Gray (Qty 1 = 1 pair)

ZSSB-E1190CH
Charcoal (Qty 1 = 1 pair)

Base Cover Accent Band
ZPS-ACCENT-1
(Qty. 1=1 pair) Sensormatic Synergy 2.5 Acrylic Pedestal

Product Compatibility
Sensormatic AM Sensors
Ranger Antenna
Satellite Antenna
Amorphous Core Antenna
Stereo Overhead Traffic Sensor
Mono Overhead Traffic Sensor
Local Device Manager II (LDM II)
UltraLink
Metal Foil Detection Plug-In Card
Digital Remote Alarm

Specifications
Height……………….. 164cm (64.6in)
Width……………….41.9cm (16.5in)
Depth……………….8.6cm (3.4in) (at base w/o covers)
Weight…………… 20.0kg (44lbs) (w/o cover)
Base cover………..1.7kg (2.6lbs)
Accent band……… 3.4kg (7.6lbs)

Electrical

Power Supply
Primary input…………..100-120Vac or 220-240Vac@50-60Hz
Primary power fuse………3.15A, 25OV slo-blow, hi-breaking (One pedestal only)
Current draw (120V)……<0.75Arms
Current draw (240V)…….<0.37Arms
Input power (120V)………<57W
Input power (240V)………..<57W

Transmitter
Operating Frequency……..58kHz +/-200Hz (sync pulse) 56kHz
Transmit Burst Duration………………..1.6ms
Transmit Current mzx………………20A peak

Burst Repetition Rate
Based on 50Hz ac…………..75Hz or 37.5Hz
Based on 60Hz ac…………….90Hz or 45Hz

Receiver
Center Frequency………………………. 58kHz

Environmental Constraints
Ambient Temperature
0°C to 50°C (32°F to 122°F)

Relative Humidity
0 to 90%, non-condensing
Enclosure Rating
IPXO
Evaluated for altitudes less than 3000m (9800ft)

Declarations

EMC
47 CFR, Part 15
EN 300 330-2
EN 301 489-3
EN 301 489-1
EN55022
EN55024
ICES-003
RSS-210

Safety
UL 60950-1 (second edition)
CSA C22.2.60950-1
EN 60950-1

Loss Prevention Systems is a Global Authorized Partner – Contact us today for information the Sensormatic Synergy 2.5 Acrylic Pedestal product.
