Door-Max by Sensormatic®

Attractive, slender design compliments any store environment. Details on Door-Max by Sensormatic

The Door-Max features Sensormatic AM EAS technology in an attractive, slender antenna to protect exits up to 1.8m (6ft) wide. Attached to door frames, glass and other surfaces, this detection system compliments any store decor whether in a shopping mall or a stylish boutique. The Door-Max is compatible with Sensormatic auxiliary receivers for a cost-effective alternative with comparable detection performance. The integrated audio and visual alarms notify store personnel if protected merchandise passes through the detection zone.

Through system configuration, “Tags-too- Close” is an offered feature developed to help store associates better manage merchandising of tagged goods at the front of the store. This feature helps reduce unnecessary and costly service calls and decreases nuisance alarms to enhance the shopper experience.

Another system-configured feature is Jammer Detection. This software triggers a pedestal alarm as soon as an electronic signal from a Jammer device is detected; helping eliminate the threat of would-be thieves using this method.

Door-Max provides in-store EAS and Traffic Intelligence when connected to a compatible data management device to
better manage store operations.

Retailer Values

  • Sleek, modern antenna compliments any store entrance
  • Built-in visual and audible indicators immediately notify store associates of alarm events
  • When connected to a compatible data management device, this system provides in-store EAS and Traffic Intelligence to better manage store operations
  • “Tags-too-Close” feature helps reduce unnecessary and costly service calls and helps manage merchandising of tagged products at the store front
  • Jammer Detection helps reduce shrink by notifying staff of attempts to disable the EAS system using a separate audible alarm

Product Compatibility

Sensormatic AM Sensors

Ranger Receivers

Satellite Receivers

Amorphous Core Receiver

Stereo Overhead Traffic Sensor

Mono Overhead Traffic Sensor

Local Device Manager II (LDM II)

UltraLink

Digital Remote Alarm

Specifications

Height…………183.9cm (72.4in)

Width……………24cm (9.4in)

Thickness/Depth…….. 4.4cm (1.7in)

Weight…….. 11.6kg (25.5lbs)

Electrical

Receiver Center Frequency…………. 58kHz

Receive Coil Resistance……. 1.6 ohms (±5%)

Alarm Audio Level………..109dBA

Environmental Constraints

Ambient Temperature

0°C to 50°C (32°F to 122°F)

Relative Humidity

0 to 90%, non-condensing

Enclosure

IPx0

Evaluated for altitudes less than

3200m (10,500ft)

Declarations

EMC

47 CFR, Part 15

EN 300 330

EN 301 489

RSS 210

Safety

EN 60950-1

Loss Prevention Systems is a Global Authorized Partner – Contact us today for information on Door-Max by Sensormatic.
