APX Sheet Label by Sensormatic

The Advanced Performance Xtreme (APX) Sheet Label delivers top-of-the-line performance and superior merchandise protection using proven Sensormatic technology. The APX Label provides exceptional range, sensitivity, tamper resistance, detection and consistent deactivation at the point-of-sale (POS) with virtually no nuisance alarms. This robust and stable AM EAS label operates efficiently after exposure to environmental stresses, including shipping and handling.

Available for in-store hand application, this label can also be applied to merchandise at the point of manufacturing so retailers can receive floor-ready merchandise with consistent label placement-expediting receiving and selling floor fulfillment.

Retailer Values

  • Utilizes proven Sensormatic AM technology and manufacturing process to provide reliable detection performance
  • Quality materials and precision manufacturing help deliver consistent deactivation at the POS
  • Small label footprint minimizes impact on brand promotion and important product information
  • Robust construction provides optimal merchandise protection
  • Works well on liquids, foils and in metal shopping carts
  • Reactivatable for unlimited reuse

Product Codes

ZLAPXS1: White

ZLAPXS2: Mock Barcode

ZLAPXS5: Black



Product Compatibility

Sensormatic AM detection and deactivation devices.

Environmental Constraints


Maximum storage temperature not to exceed 50°C (122°F) for 96 hours at 80% RH.


Unaffected by 80% humidity at 50°C (122°F), up to 96 hours.

Shelf Life

Two years from date of manufacture when labels are stored between 15°C-32°C (60°F-90°F), 30-80% RH.

Mode of Application


Materials of Construction

Plastic Substrate

Polystyrene/Polyethylene 0.254mm (0.010in) thickness

Magnetic Acoustic Resonator

Proprietary resonant magnetic material

Amorphous alloy based on iron, containing nickel, cobalt, boron and silicon


Low Density Polyethylene/Polyester 0.101mm (0.004in)


Proprietary semi-hard magnetic material containing iron and nickel


Double-coated, rubber-based adhesive:

• 2.4 mil thick each side

• Minimum peel strength of 2.27kg/5lbs

Release Liner

Double-sided, silicon-coated 2 mil polyester


Color……..White, Mock Barcode, Black

Length………45.21mm ± 0.5mm (1.78in ± 0.020in)

Width……..10.67mm ± 0.5mm (0.420in ± 0.020in)

Label Thickness

(excluding liner)……… Maximum 1.89mm (0.074in)

(including liner)……… Maximum 2.00mm (0.079in)

Labels Per Sheet………..108

Loss Prevention Systems is a Global Authorized Partner – Contact us today for information on Sensormatic products.

Note: Warranty terms and conditions are as specified in the applicable Sales Agreement.
